D16 PunchBox 2: 808 Kick Designer for Beatmakers 2026

This Page Is PunchBox 2 for 808 Kicks. It Is Not a Drum Machine.

Stay here for D16 Group PunchBox 2 as a beatmaker kick tool: 808 / 909 / 606 / wavetable body, sample layers, and WAV export into FL Studio. Do not use this page as a full kit review, a PunchBox 1 tutorial, or a “best trap VST” roundup. Related trap-plugin and XO sequencer pages cover those jobs.

KVR’s news post is dated 26 June 2026. Attack Magazine’s launch write-up is the same day. CDM’s hands-on ran 29 June 2026. This September 2026 file is that v2 SKU, not a claim that PunchBox 2 first shipped this month.^[1][2][4]

PunchBox 2 is a bass-drum design engine. It does not sequence hats, claps, or a 16-pad kit. If you need a sample-free drum machine with a step sequencer, use the related Tekno 1.1 page. If you need a drum-browser / sequencer, use the related XO 2 page.

Four Generators. Kick Mode Includes 808, 909, 606, Sample, Wavetable.

Attack: PunchBox 2 is built around four sound generators. Three are universal sample layers for transients, body, noise, or supporting material. The main Kick generator runs five modes: Sample, 909, 808, 606, and Wavetable. That is the 808 path this page cares about—tune the 808 engine, then layer a click/sample on top.^[2]

D16’s product page: three multi-purpose sample layers plus a main Kick generator that switches between sample playback and synthesis models inspired by classic drum machines, plus a dedicated Wavetable mode (position, phase, level, filter, modulation). Content is a collaboration with Sounds of Revolution and CFA-Sound.^[3]

CDM: version 1 labeled the sample layers Click / Tops / Tools; v2 numbers them 1–3 so you decide the job. CDM also notes v1’s sine generator is gone—wavetable and the Advanced Editor replace that slot. Keep PunchBox 1 only if you still need that sine module.^[4]

• Factory counts: use D16’s page Product page: 1,505 factory samples, 1,119 Master Presets, 241 Kick Presets, 66 wavetables, plus bitcrusher/distortion preset banks. Attack and Synth Anatomy printed 1,506 / 1,120 / 243. Quote the live product page until D16 changes it.^[3][2][6]
• Pitch tools Attack: real-time pitch detection to tune kicks inside the instrument. Official walkthrough: export the same kick at chosen notes for a playable 808 bassline. Sounds of Revolution: Keytrack follows MIDI notes so exported WAVs stay consistent across pitches.^[2][5][7]
• Multi-out is optional D16 back panel: route individual generators to separate DAW outputs, with or without the FX chain; master trim 0 / −6 / −12 dB. Use it when you want your own saturator on the click. Skip it when you only need a stereo WAV.^[3]

WAV Export Is Built In. Drop the File into FL Studio.

D16: when the sound is dialed in, render it to an audio file and drag-and-drop it into the project. The official walkthrough says the same in plain language: export as a WAV or drag it straight into the DAW, and choose which note gets rendered so you can build a pitched 808 bassline.^[3][5]

That is not an FL-only feature. FL Studio is just the common beatmaker host: VST3 insert, or bounce a WAV onto the Playlist / Channel Rack and sequence it like any other 808 one-shot. Attack names drag-and-drop WAV export as a workflow addition. CDM: v2 export adds pitch, normalization, duration, and a target folder so you can assemble a folder of samples at once.^[2][4]

Sounds of Revolution (content partner): the export window controls duration, note, octave, velocity, and amplitude normalization. Keytrack turns the bass drum into a playable 808 generator; exported WAVs reuse in any sampler. That is the CPU-saving path: design once, then run a WAV in FL instead of keeping the synth open.^[7]

As of Sep 2026: D16 List €99. Intro €79/$89 Is Over.

Cite the live D16 store for euros: this September 2026 snapshot shows €99 on the PunchBox 2 product page. Attack’s 26 June 2026 post listed retail €99, $109, and £85, including taxes where applicable. KVR: introductory €79 until 26 July 2026 (reg. €99). CDM: $89 (79€) through 25 July, $109 thereafter. As of this page, that intro window is closed.^[3][2][1][4]

KVR: special upgrade offers for PunchBox 1 owners and loyal D16 customers via email and the User Area. Synth Anatomy’s launch-day note: PunchBox 1 owners could upgrade for €25 with a coupon from the user account. Treat €25 as that launch-day report, not a guaranteed September 2026 cart total—log into the User Area and read the live coupon.^[1][6]

Formats on KVR/Attack/D16: VST2, VST3, AU, AAX. D16 requirements: Windows 7+ (32- or 64-bit hosts); macOS 10.13 through macOS 26, Intel and Apple Silicon, 64-bit only. Not a standalone app. Demo installers are on the product page.^[3][2]

Hats, Full Kits, and PunchBox 1 Sine Mode Are Out of Scope

PunchBox 2 designs kicks. It does not replace a drum rack, XO, or a sample-free kit synth. CDM’s review is kick-focused for a reason. If you need a sequenced kit, leave this page.^[4]

This is not a Serum bass-design tutorial. Related “how to design bass in Serum” covers wavetable 808s inside Serum. PunchBox’s wavetable mode is a kick oscillator, not a general synth.

D16’s current Windows installer on the product page is PunchBox 2.1.0. The public changelog for 2.1.0 adds undo/redo, preset export/import with samples, and sample-browser fixes; 2.0.1 is dated 2 July 2026. This article stays on the 2.x kick-designer SKU, not a 2.1.0 feature-by-feature patch note.^[8]

Design the Kick Once. Export WAV. Sequence It in FL.

This checklist is the 808 one-shot path. Confirm the live D16 manual for your build before you change a template.^[3]

1. Load PunchBox 2 as VST3 in FL Studio
   Formats: VST2, VST3, AU, AAX. FL on Windows uses VST3. There is no standalone. Rescan plugins if the 2.x binary does not appear.^[3]
2. Set Kick mode to 808 (or Wavetable if you need a non-classic sub)
   Five Kick modes: Sample, 909, 808, 606, Wavetable. Layer 1–3 for click and mid. Use pitch detection to match the song key before you bounce.^[2]
3. Export WAV at the notes you will sequence
   Export button or drag-and-drop. Walkthrough: pick the render note so one kick becomes a pitched 808 set. CDM: set duration, normalization, and a target folder.^[5][4]
4. Drop the WAV on the FL Playlist or Channel Rack
   Treat it as a one-shot. Keep PunchBox open only if you still need Keytrack MIDI or multi-out. Sounds of Revolution: exported WAVs are the CPU-saving library path.^[7]
5. Do not treat this page as the mix
   Limiter/clip inside PunchBox is optional. If the 808 collides with the bass, that is arrangement—not a PunchBox preset problem. This file stops at the kick designer.
